Superabrasives (CBN / diamond grinding tools)
Tailored precision high-performance tools for high-end applications and precision at the highest level.
Manufacturing process
- THELEICO high-tech ceramic bonds were developed for using the different CBN and diamond grain types
- Optimal incorporation of the grain and high grain retention forces due to coordinated viscosity and boundary surface reactions between grain and bond at low firing temperatures
- Highest resistance to abrasive wear
- Finishing / selection of supports according to customer's requirements
- Tested under internationally recognised safety standards
Properties
- Lowest wear, highest service life
- Possible to manufacture highly porous tools with controlled porosity
- Particularly good coolant transport and good stock removal
- Highest stock removal rate
- High temperature stability (wet grinding predominantly used)
- Designed for reproducible high-performance serial production processes
- Used for new high-performance materials
Delivery range
- Diameter: from 5 to 750 mm
- Width: up to 300 mm
- In all shapes according to ISO / EN standards or drawings
- Cutting speeds up to 140 m/s
- Supports made of ceramic, synthetic resin, aluminium and steel as well as vibration-reducing supports
- CBN and diamond in all variations and concentrations
